CH-6 CHARGING SYSTEM — PREPARATION
PREPARATION
SST (SPECIAL SERVICE TOOLS)
CiD0O—¢
J.-*1
Q/
/iv
%
09216-00021 Belt Tension Gauge
1
09216-00030 Belt Tension Gauge Cable
)
I
I »/,1»//////u/W/I
09285-76010 Injection Pump Camshaft Bearing
Cone Replacer
Rotor rear bearing cover
\==1
09286-4601 1
Injection Pump Spline Shaft
Puller I
Rectifier end frame
i Z f(@
09608 -20012
(09608 - 00030)
Front Hub & Drive Pinion Bearing
Tool Set
Replacer IIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIII H Rotor front bearing
e
09820 -00021 Alternator Rear Bearing Puller Rotor rear bearing
L-{Z
FE
09820-00030 Alternator Rear Bearing Replacer Rotor rear bearing
%
09820 -63010 Alternator Pulley Set Nut Wrench
Set
RECOMMENDED TOOLS
C0flI—0A
_ ,4
\,
tits it
09082 -00050 TOYOTA Electrical Tester Set
Qw-=55
m?
09200 -00010
Engine Adjust Kit
%
09905-00013 Snap Ring Pliers Alternator washer for ST202
