STARTING SYSTEM — SERVICE SPECIFICATIONS
ST-23
SERVICE SPECIFICATIONS
SERVICE DATA
I'TO1l—0M
Starter Rated voltage end output power
No—-load characteristics
Brush length
Spring installed load
Commutator
Diameter
Undercut depth
Circle runout
Current
rpm
STD
Limit
STD
Limit
STD
Limit
Limit
12 V 1.4 kW
90AorIessat11.5V
3,000 rpm or more
15.0 mm (0.591 in.)
8.0 mm (0.315 in.)
12 — 20 N (1.2 — 2.0 kgf, 2.6 — 4.4
30 mm (1.18 in.)
29 mm (1.14 in.)
0.6 mm (0.024 in.)
0.2 mm (0.008 in.)
0.05 mm (0.0020 in.)
TORQUE SPECIFICATIONS
IT°1I~@
Part tightened
ft-lbf
End cover x Brush holder
13 in.-lbf
Starter housing x Magnetic switch 5.9 60
52 in.-lbf
End cover x Starter Housing
5.9 60 52 in.-lbf
Lead wire of field frame x Magnetic switch
7.9 81
N-m kgf-cm
1.5 15
70 in.-lbf
