CDM-625 Advanced Satellite Modem
Front Panel Operation
5.4.1

CONFIG: All

All = Stop
(Stop, Start)
This menu permits the user to configure the unit, in a step-by-step process, by viewing each menu in
succession. Use the
Press ENTER to continue through all the configuration. Press CLEAR to discontinue.
5.4.2

CONFIG: Mode

The MODE is a key parameter when configuring the modem. To simplify the menu
choices, the user must first determine the INTERFACE and FRAMING type for both
Transmit and Receive. Once these have been selected, the user is only presented
IMPORTANT
with menu choices that are applicable to those particular modes.
Examples:
•
•
Mode:
(422,V35,G703s,Audio,LVDS,HSSI,IP,ASI)
Both Interface type and Framing of both Tx and Rx may be selected from this menu. Select the
parameter to edit using the
on the lower line. Not all options are always available: they depend on other settings or on the FAST
options of the modems. The above display depicts an Interface Type editing example.
If the cursor is on the Framing Type, the display appears as shown:
Mode:
(None IBS IDR D&Is EDMACs ESC++)
Scroll through the available options using the
The first parameter is the Interface type. The options are:
•
RS422
•
V.35
•
G.703s
G.703B (balanced)
o
G.703U (unbalanced)
o
◄ ►
arrow keys to select and
If a G.703 interface is selected, the data rate menu will be restricted to only
the appropriate G.703 rates.
If an IDR framing mode is selected, the data rate choices will be limited to
only those rates specified by IESS-308.
Tx=RS422:NONE
◄ ►
arrow keys. The options available for this parameter are indicated
Tx=RS422:NONE
MN-0000036 (Ref MN/CDM625.IOM)
arrow keys to edit the various parameters.
▲ ▼
Rx=RS422:None
Rx=RS422:None
arrow keys, then press ENTER.
▲ ▼
5–8
Revision 1
