CDM-Qx Satellite Modem
Front Panel Operation
5.7.5.1 (Save/Load%Save) – SAVE CONFIGURATION
Selecting Save displays the following screen, if the selected location is empty:
Save Config to Location: 9
Empty
However, if the location already contains data, the following screen is displayed:
Save Config to Location: 9
11:10:29 23/12/03
The user is shown the time and date stamp of the previously stored configuration, for
identification purposes.
Locations 1 through 10 are available. Select the location to which to store the current
configuration, using the #$ arrow keys, then press
not contain a previously stored configuration, the following screen is displayed:
Your Configuration has been
Saved to Location 9
Pressing
If, however, the selected location contains a previously stored configuration, the
following screen is displayed:
Location 9 Contains Data!
Overwrite? NO YES
Select NO or YES using the ◄ ► arrow keys, then press
overwrite the existing configuration at the selected location.
5.7.5.2 (Save/Load%Load) – LOAD CONFIGURATION
Having selected Load, if there is a configuration stored at the selected location the
following screen is displayed:
Load Config from Location: 9
11:10:29 23/12/03
Note the data and time stamp identifying the stored configuration. If the selected location
contains no data, the following screen is displayed:
Load Config from Location 9
Empty
or takes the user back to the previous menu.
ENTER CLEAR
(▲ ▼ ENT)
(▲ ▼ ENT)
ENTER
(ENT)
(◄ ► ENT)
(▲ ▼ ENT)
(▲ ▼ ENT)
5–58
Revision 6
MN/CDMQx.IOM
. If the selected location does
. Selecting YES will
ENTER
