CDM-570A/570AL Satellite Modem with Optional Packet Processor
Front Panel Operation
If the selected location already contains data, then the time and date stamp of the previously
stored configuration displays for identification purposes, as this example shows:
Save Config to Loc: 9
11:10:29 23/12/13 (▲ ▼)
If the selected location does not contain a previously stored configuration, the screen appears as
this example shows:
Your Configuration has
been Saved to Loc 9 (ENT)
Press ENTER or CLEAR to return to the previous menu.
If the selected location does contain a previously stored configuration, the modem prompts you
to overwrite the location. The screen appears as this example shows:
Loc 9 Contains Data!
Overwrite? NO YES
◄ ►
Use the arrow keys to select No or Yes. Press ENTER. Select Yes, if prompted, to overwrite
the selected location's existing configuration.
Once you properly save a modem configuration, press ENTER or CLEAR to return to the previous
menu.
6.3.6.2

(Save/Load Configuration:) Load

Use the ▲▼arrow keys to select the location of the modem configuration that is to be retrieved
for loading. Press ENTER. Locations 0 through 9 are available.
Using Location 9 as an example: If you select Load and a configuration is stored at the chosen
location, the time and date stamp of the previously stored configuration displays for identification
purposes, as this example shows:
Load Config from Loc: 9
11:10:29 23/12/13 (▲ ▼)
If the selected location contains no configuration data, the screen appears as this example
shows:
Load Config from Loc 9
Empty
Use the ▲▼arrow keys to select another location from which to load a configuration (e.g.,
Location 8). Press ENTER. If the newly selected location contains valid data, the display appears
as this example shows:
(◄ ►)
(▲ ▼)
