D.6.2

Technical data of the operator panel with display

Mounting
Display
• Red/green/yellow "DEVICE" LED
• Green "BUS" LED
• Red "GEN. FAULT" LED
• 4 green LEDs
Display
Buttons
• Control buttons
• Arrow keys
• Softkeys
System interfaces
• Front
• Rear
Table D-13: Technical data of the operator panel with display
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
Installation in a switchgear cabinet door or in a front panel,
with IP54 system interface cover.
• Red: Blocked
"Function test was negative, device is
blocked"
• Green:
"Ready for operation"
• Flashing green:
"No connection to basic unit"
• Yellow:
"Memory module or addressing plug
detected"
• OFF:
"No control supply voltage"
• Continuous light:
"Communication with PLC/PCS"
• Flashing:
"Baud rate recognized/communication
with PC/programming device"
• Continuous light/
"Feeder fault", e.g. overload tripping
flashing:
For freely-assigning any status signals (preferably for feedback
on the switching state, e.g. ON, OFF, LEFT, RIGHT)
Graphic display of current measured values, operating and
diagnostics data or status information.
• Control of the motor feeder, freely assignable
• Navigation in the display menu
• Various functions, depending upon the menu, e.g. test,
reset, operation of memory module and addressing plug
For connecting a memory module, an addressing plug or a PC
cable for parameterization purposes.
Connection to the basic unit or expansion module

Technical data

D-23
