Operator panel buttons
The following diagram shows the front view of the operator panel and
buttons:
Fig. 7-3: Operator panel buttons
Buttons on the operator panel with display
The following diagram shows the front view of the operator panel with
display and buttons:
Button 1
Button 2
Button 3
Button 4
Fig. 7-4: Buttons on the operator panel with display for SIMOCODE pro V
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
Button 1 Button 2 Button 3 Button 4 Button
DEVICE
GEN. FAULT
BUS
Inputs
"Test/Reset"
TEST/
RESET
7-7
