Technical data
D.5

Technical data of the expansion modules

D.5.1

Technical data of the digital modules

Mounting
Display
• Green "READY" LED
System interfaces
Control circuit
Rated insulation
voltage U
i
Rated impulse withstand voltage
U
imp
Relay outputs
• Number
• Function
• Stipulated short-circuit protection
for auxiliary contacts (relay
outputs)
• Rated uninterrupted current
• Rated switching capacity
Inputs (binary)
• 24 V DC
Cable lengths (single)
Input characteristic
• 110 V - 240 V AC/DC
Cable lengths (single)
Input characteristic
D-10
Snap-on mounting onto 35 mm standard mounting rails or
screw attachment via additional plug-in lugs
• Continuous light: "Ready for operation"
• Flashing: "No connection to basic unit"
For connecting to a basic unit, an additional expansion
module, a current measuring module or a current/voltage
measuring module or the operator panel
300 V (for Degree of Pollution 3)
4 kV
2 monostable or bistable relay outputs (depending on version)
Isolated NO contacts (NC contact response parameterizable
via internal signal conditioning), relay outputs all with common
ground, freely-assignable to control functions (e.g. network,
star or delta contactor or operating state status information).
• Fuse links, operating class gL/gG 6 A, quick-response 10 A
(IEC 60947-5-1)
• Miniature circuit breaker 1.6 A, C-characteristic
(IEC 60947-5-1)
• Miniature circuit breaker 6 A, C-characteristic (I
5 A
6 A at max. +50 °C
AC-15 6 A/24 V AC 6 A/120 V AC
DC-13 2 A/24 V DC 0.55 A/60 V DC
4 externally supplied, isolated inputs (24 V DC or 110 V - 240 V
AC/DC, depending on version), with common ground for
measuring process signals (e.g. local control station, key-
operated switches, limit switches, ...), freely-assignable to
control functions.
300 m
Type 2 according to EN 61131-2
200 m (cable capacitance 300 nF/km)
—
< 500 A)
k
3 A/230 V AC
0.25 A/125 V DC
