Example circuits
E.15
"Soft starter with reversing contactor" example circuit
E.15.1
Circuit diagram "Soft starter with reversing contactor" (3RW402, 3RW403,
3RW404)
Fig. E-41: Circuit diagram "Soft starter with reversing contactor" (3RW402, 3RW403, 3RW404)
E-46
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
