Inputs
Schematic
The following schematic shows the "OP Buttons" function block:
Fig. 7-5: Schematic of the "OP Buttons" function block
1) Operable via the menu on the operator panel with display
7-8
Button 1
OP Buttons
Button 2
Button 3
Button 4
Button
1)
Test/Reset
OP Button 1
OP Button 2
OP Button 3
OP Button 4
OP - Test/Reset button
GWA 4NEB 631 6050-22 DS 03
SIMOCODE pro
