Communication
Station status 2
Bit
0 The DP slave must be parameterized again.
1 There is a diagnostic message. The DP slave will not function until the fault is
rectified (static diagnostic message).
2 The bit is always "1" when the DP slave with this PROFIBUS address is present.
3 Address monitoring is activated for this DP slave.
4 The DP slave received the "FREEZE" control command
5 The DP slave received the "SYNC" control command
6 0: Bit is always "0".
7 The DP slave is deactivated, i.e. it is decoupled from the current
processing.
1)
Bit is only updated if another diagnostic message also changes.
Table 12-4: Configuration of station status 2 (byte 1)
Station status 3
Station status 3 is not relevant for the slave diagnostics.
Bit
0 to 7
Table 12-5: Configuration of station status 3
Master PROFIBUS address - definition
The PROFIBUS address of the DP master (class 1 master) is stored in the
"Master PROFIBUS address" diagnostic byte which:
• Parameterized the DP slave
• Has read and write access to the DP slave.
The master PROFIBUS address is in byte 3 of the slave diagnostics.
Manufacturer's identification - definition
A code is stored in the manufacturer's identification which describes the DP
slave type.
Byte 4
80
H
Table 12-6: Configuration of the manufacturer's identification
12-10
Bits are always "0".
Byte 5
FD SIMOCODE pro
H
Meaning
1)
1)
.
Meaning
Manufacturer's identification for
GWA 4NEB 631 6050-22 DS 03
.
SIMOCODE pro
