Siemens SIMOCODE pro System Manual page 73

I_max, Cos (example)
I_max, UL1-N, Cos, S
I_max, UL1-L2, Cos, S
I_max, UL1-N, Cos, P
I_max, UL1-L2, Cos, P
Table 1-10: Read and adapt main display (Cont.)
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
Displays the maximum current of all three phases in A and the
power factor.
Note
Only possible if a current/voltage measuring module is being used.
Displays the maximum current of all three phases in A, the phase
voltage UL1-N in V, the power factor, and the apparent power
in kVA.
Note
Only possible if a current/voltage measuring module is being used.
If an OPD above version *E04* is used: Values will only be
displayed if phase voltage is set/configured.
Displays the maximum current of all three phases in A, the line-to-
line voltage UL1-L2 in V, the power factor, and the apparent power
in kVA.
Note
Only possible if a current/voltage measuring module is being used,
line-to-line voltage is set/configured and the OPD is above version
*E04*.
Displays the maximum current of all three phases in A, the phase
voltage UL1-N in V, the power factor, and the apparent power
in kVA.
Note
Only possible if a current/voltage measuring module is being used.
If an OPD above version *E04* is used: Values will only be
displayed if phase voltage is set/configured.
Displays the maximum current of all three phases in A, the line-to-
line voltage UL1-L2 in V, the power factor, and the apparent power
in W.
Note
Only possible if a current/voltage measuring module is being used,
line-to-line voltage is set/configured and the OPD used is above
version *E04*.
System description
1-55
