Mounting, wiring, interfaces
Analog module pin assignment
The following table shows the pin assignment of the removable terminals:
Connection
Upper terminals
30
31
33
34
Lower terminals
36
37
PE
Table 13-9: Pin assignment of the removable terminals of the analog module
13-22
Assignment
Analog input IN1+
Analog input IN2+
Analog input IN1+
Analog input IN2+
Analog output OUT+
Analog output OUT+
System shielding
30
31
IN1+
IN2+
33
34
IN1-
IN2-
READY
AM
3UF7 400–1AA00–0
G/YYMMDD
Exx
*
*
36
37
PE
+OUT-
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
