3 Status display motor protection/motor control (OPD)
For details see
Fig. 1-20: Status display motor protection/motor control (OPD)
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
"Motor protection and motor control
General fault
General warning
Current flowing
Device ok
Bus ok
PLC/PCS in Run
ON <<
OFF
ON >>
Interlocking time active/
Change-over pause act.
OPO
Remote
TPF
FC
TC
Positioner...
Closes
Opens
Non-maintained
command mode
Cooling down period act.
Pause time active
Emergency start executed
Device test
Active
Phase sequence
1-2-3
Safety
Enabling circuit
Switch-off
Safety o.k.
DIP Safety
1 4
2 5
3 6
Safety
Enabling circuit
Switch-off
PROFIsafe o.k.
System description
status".
ON <
ON >
Start active
FO
TO
3-2-1
DM-F Local
(OPD above *E04* and BU2 above *E07*)
DM-F Local
7
8
(OPD above *E04* and BU2 above *E07*)
DM-F PROFIsafe
(OPD above *E04* and BU2 above *E07*)
