Technical data
D.6

Technical data of the operator panels

D.6.1

Technical data of the operator panel

Mounting
Display
• Red/green/yellow "DEVICE" LED
• Green "BUS" LED
• Red "GEN. FAULT" LED
• 3 yellow LEDs / 4 green LEDs
Buttons
• Test/Reset
• Control buttons
System interfaces
• Front
• Rear
Table D-12: Technical data of the operator panels
D-22
Installation in a switchgear cabinet door or in a front panel, with
IP54 system interface cover.
• Red: Blocked "Function test was negative, device is
blocked"
• Green: "Ready for operation"
• Flashing green: "No connection to basic unit"
• Yellow: "Memory module or addressing plug
detected"
"No control supply voltage"
• OFF:
• Continuous light: "Communication with PLC/PCS"
• Flashing: "Baud rate recognized/communication
with PC/programming device"
• Continuous light/ "Feeder fault", e.g. overload tripping
flashing:
For freely assigning any status signals
• Resetting the device after tripping
• Function test (system self-test)
• Operation of memory module, addressing plug
• Control of the motor feeder, freely assignable
For connecting a memory module, an addressing plug or a PC
cable for parameterization purposes
For connecting a cable to the basic unit or the expansion
module
