The following schematic shows the cooling off response with and without
pause time:
Motor
ON
OFF
Thermal memory (motor model)
Without pause time
100 %
With pause time
100 %
Fig. 3-4: Cooling down response with and without pause time
Notice
Both the motor and the switching devices must be dimensioned specifically
for this load!
Pause time:
Type of load
You can select whether SIMOCODE pro is to protect a 1-phase or a 3-phase
load.
For a single-phase type of load, Monitor Earth Fault and Unbalance
Protection must be deactivated.
Phase Failure Monitoring is deactivated automatically.
Type of load:
See Table 1-20: Decoupling module requirements for star networks
1-97.
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
Pause time
Thermal memory will be deleted after the pause time
elapses
0 to 6553.5 seconds
1-phase, 3-phase
Motor protection
t
Trip level
Overload trip
t
Trip level
No overload trip
t
