D.4

Technical data of the decoupling module

Mounting
Display
• Green "READY" LED
System interfaces
Connection cross sections
• Tightening torque
• Connection cross sections:
- Solid
- Finely stranded, with end sleeve
Table D-4: Technical data of the decoupling module
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
Snap-on mounting onto 35 mm standard mounting rails or
screw attachment via additional plug-in lugs.
The left interface is for connection to a basic unit or an
expansion module, the right interface is exclusively for
connection to a current/voltage measuring module.
TORQUE: 7 LB.IN - 10.3 LB.IN
0.8 Nm - 1.2 Nm
2 2
2x 0.5 mm - 2.5 mm / 1x 0.5 mm - 4 mm
2x AWG 20 to 14/1x AWG 20 to 12
2 2
2x 0.5 mm - 1.5 mm / 1x 0.5 mm
2x AWG 20 to 16/1x AWG 20 to 14
Technical data
2
2 2
- 2.5 mm
D-9
