Data formats and data records
B.15

Data record 139 - Marking

The diagnostics
• External fault 1 to 6 (status information, warnings and faults)
• Limit 1 to 4 (status information)
• TM warning T>/tripping T> (status information, warnings and faults)
• Warning/tripping 0/4 - 20 mA mA<> (status information, warnings and
faults)
can be parameterized to have various meanings e.g. fill level >, bearing hot,
etc. To simplify diagnostics, these texts can be saved in the device. These
can be created, read out and displayed, for example, with SIMOCODE ES
The texts do not contain any functions.
Byte.Bit
0.0 Reserved
4.0 Reserved
10.0 Marking - External fault 1
20.0 Marking - External fault 2
30.0 Marking - External fault 3
40.0 Marking - External fault 4
50.0 Marking - External fault 5
60.0 Marking - External fault 6
70.0 Reserved
80.0 Reserved
90.0 Marking - Limit 1
100.0 Marking limit 2
110.0 Marking limit 3
120.0 Marking limit 4
130.0 Marking - TM warning T>
140.0 Marking - TM trip T>
150.0 Marking - Warning 0/4-20 mA>
160.0 Marking - Warning 0/4-20 mA<
170.0 Marking - Trip 0/4-20 mA>
180.0 Marking - Trip 0/4-20 mA<
190.0 Reserved
Table B-16: Data record 139 - Marking
B-40
Designation Type Information
Byte[4]
Byte[6]
Byte[10] BU1 BU2
Byte[10] BU1 BU2
Byte[10] BU1 BU2
Byte[10] BU1 BU2
Byte[10] BU2
Byte[10] BU2
Byte[10]
Byte[10]
Byte[10] BU2
Byte[10] BU2
Byte[10] BU2
Byte[10] BU2
Byte[10] BU2
Byte[10] BU2
Byte[10] BU2
Byte[10] BU2
Byte[10] BU2
Byte[10] BU2
Byte[10]
