System description
Status display for PROFIBUS communication
The "Communication" menu item displays all important information
concerning PROFIBUS communication. In addition to the current PROFIBUS
device address, the baud rate or PROFIBUS-relevant settings concerning
process alarms and diagnostic alarms for the automation system are also
displayed.
Here are the most important menus:
PROFIBUS address (example)
PROFIsafe address
Baud rate
Bus o.k.
Bus monitoring
Table 1-14: Status display for PROFIBUS communication
1-72
Displays the PROFIsafe address.
Note
This is only displayed if the OPD version is above *E04* and if the
BU 2 is above version *E07* with a DM-F PROFIsafe present.
