Siemens SIMOCODE pro System Manual page 95

Digital module 1, digital module 2
Inputs 1, 2, 3, 4
Monostable outputs
Bistable outputs
Table 1-15: Displays the current status of all device I/Os (Cont.)
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
Inputs 1, 2, 3, 4 "monostable" or "bistable".
Note
Only possible if digital module 1 is being used as monostable or
bistable.
Outputs 1, 2 "monostable".
Note
• Only possible if digital module 1 is being used as monostable.
• For OPDs up to version *E03*: The display is different.
Bistable outputs 1, 2.
Note
• Only possible if digital module 1 is being used as monostable.
• For OPDs up to version *E03*: The display is different.
System description
1-77
