1.7.10

Software

For communication-capable switching devices, device functions, hardware
configuration, user-friendliness of parameterization software and suitable
system integration (i.e. optimum and fast integration in various plant
configurations and process automation systems) play a key role.
SIMOCODE pro offers various software tools for thorough, time-saving
parameterization and configuration and diagnostics for:
• SIMOCODE ES for "totally integrated" commissioning and service
• Object manager OM SIMOCODE pro for "totally integrated" in SIMATIC S7
• PCS 7 SIMOCODE pro function block library "totally integrated" in PCS 7
SIMOCODE ES
SIMOCODE ES is the standard parameterization software for
SIMOCODE pro, and runs on a PC/PD with Windows XP or Windows 7
Ultimate and Professional.
SIMOCODE ES is a user-friendly and clear user interface for the
SIMOCODE pro motor management system for parameterizing, operating,
monitoring and testing SIMOCODE in the field or from a centralized
location.
SIMOCODE ES provides detailed information for maintenance and service
by displaying operating, service and diagnostic data and helps to prevent,
localize and resolve faults.
Online parameterization during operation avoids unnecessary plant
downtime.
The integrated print function in SIMOCODE ES makes it possible to
document all parameters according to DIN EN ISO 7200.
Additionally, the graphics editor allows very ergonomic and user-friendly
parameterization per "drag and drop": Inputs and outputs of function blocks
can be linked graphically and the parameters set. Configured functions can
be described in detail and device parameterization can be documented
graphically using comments. This speeds up commissioning and simplifies
plant documentation. The optimized user interface and integrated graphic
editor are used for parameterization. Inputs and outputs of function blocks
can be linked graphically and the parameters set. The device
parameterization can be documented graphically. See also
"Overview of function blocks
Further functions: Operation, diagnostics, testing, S7 routing, Teleservice
via MPI, STEP 7 object manager.
You will find a demo and latest updates on the Internet at
http://www.siemens.com/simocode
Note
SIMOCODE ES is subject to continual maintenance and improvement.
Current Service Packs and Hotfixes can be downloaded at
http://www.siemens.com/simocode
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
(alphabetical)".
-> Support -> Software Downloads
-> Support -> Software Downloads.
