Technical Data Of The Earth-Fault Module - Siemens SIMOCODE pro System Manual

Technical data
• Short-circuit proof
• Isolation of the output to the
device electronics
Connection:
• Tightening torque
• Connection cross sections:
- Solid
- Finely stranded, with end sleeve
Table D-9: Technical data of the analog module
D.5.6

Technical data of the earth-fault module

Mounting
Display
• Green "READY" LED
System interfaces
Control circuit
Connectable 3UL22 summation
current transformer with rated
fault currents I
N
• I < 50 % I
Earth fault N
• I > 100 % I
Earth fault N
Response delay (conversion time)
Connection:
• Tightening torque
• Connection cross sections:
- Solid
- Finely stranded, with end sleeve
Table D-10: Technical data of the earth-fault module
D-20
Yes
No
TORQUE: 7 LB.IN - 10.3 LB.IN
0.8 Nm - 1.2 Nm
2 2
2x 0.5 mm - 2.5 mm / 1x 0.5 mm
2 x AWG 20 to 14/1 x AWG 20 to 12
2 2
2x 0.5 mm - 1.5 mm / 1x 0.5 mm
2 x AWG 20 to 16/1 x AWG 20 to 14
Snap-on mounting onto 35 mm standard mounting rails or
screw attachment via additional plug-in lugs
• Continuous light: "Ready for operation"
• Flashing: "No connection to basic unit"
For connecting to a basic unit, an additional expansion
module, a current measuring module or a current/voltage
measuring module or the operator panel
0.3 / 0.5 / 1 A
No tripping
Tripping
300 ms - 500 ms, additionally delayable
TORQUE: 7 LB.IN - 10.3 LB.IN
0.8 Nm - 1.2 Nm
2 2
2x 0.5 mm - 2.5 mm / 1x 0.5 mm
2 x AWG 20 to 14/1 x AWG 20 to 12
2 2
2x 0.5 mm - 1.5 mm / 1x 0.5 mm
2 x AWG 20 to 16/1 x AWG 20 to 14
2 2
- 4 mm
2 2
- 2.5 mm
2 2
- 4 mm
2 2
- 2.5 mm
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
