Communication

SIMATIC PDM

The standard version of SIMATIC PDM (PDM Basic) provides you with a

comparable functionality to SIMOCODE ES for parameterization of

SIMOCODE pro via PROFIBUS:

The following additional functions are available with the PDM option

"Integration in STEP7":

• "Offline saving" of SIMOCODE pro parameter data in the STEP7 project and

manual transmission (no automatic transfer of parameter data during

• "Routing via S7 stations".

Example: Parameterization of all SIMOCODE pro devices from a central

engineering station, together with hardware components which provide a

data record gateway (CP443-5 Extended, IE/PB link), also in connection with

different networks.

The startup parameter block (Device Parameter > Bus Parameter) must

always be set for this form of parameterization to avoid overwriting the

device parameters with any existing parameter data during startup.

You will find further information about SIMATIC PDM in the SIMATIC PDM

SIMOCODE pro

GWA 4NEB 631 6050-22 DS 03
