System description
Profiles
See "Menu of the operator
panel with display", main
display
Table 1-16: Adapt display settings (Cont.)
1-82
Enables selection of the display profiles for the main display. If a
defined profile is no longer supported by SIMOCODE pro, for
example, due to a changed hardware configuration, the start display
is shown instead of the default main display.
• IL1, IL2, IL3 [A]
• I_max [A]
• IL1, IL2, IL3 [%]
• I_max [%]
• I_max, Cos
• I_max, UL1-N, Cos, S
• I_max, UL1-L2, Cos, S
• I_max, UL1-N, Cos, P
• I_max, UL1-L2, Cos, P
• In1/Output [mA]
• In2/Output [mA]
• Inputs [mA]
• Max. temp. °C
• Temperatures °C
• Max. temp. °F
• Temperatures °F
• UL1-N, UL2-N, UL3-N
• UL1-L2, UL2-L3, UL3-L1
• I_max, UL1-N, Cos
• I_max, UL1-L2, Cos
• I_max, UL1-N, °C (max. temp.)
• I_max, UL1-L2, °C (max. temp.)
• I_max, UL1-N, °F (max. temp.)
• I_max, UL1-L2, °F (max. temp.)
• Calculator 1
• Calculator 2
• Energy consumed [kWh]
