A.5

Detailed messages of the slave diagnostics

The following table contains the detailed messages of the slave diagnostics
for status information and the process alarm. This information is also
contained in data record 92.
Byte.Bit
0.0 Trip - Controlling
0.1
0.2
0.3
0.4
0.5
0.6
0.7
1.0
1.1
1.2
1.3
1.4
2.0
2.1 Trip - Protection
2.2
2.3
2.4
2.5
2.6
2.7
3.0
3.1
3.2
3.3
3.4
3.5
3.6
4.0 Trips -
Level monitoring
4.1
4.2
4.3
4.4
4.5
4.6
4.7
5.0
5.1
Table A-5: Detailed messages of the slave diagnostics
A-14
Status information
Trip - Execution ON command
Trip - Execution STOP command
Trip - FB ON
Trip - FB OFF
Trip - Stalled positioner
Trip - Double 0
Trip - Double 1
Trip - End position
Trip - Antivalence
Trip - Cold starting (TPF) fault
Trip - UVO fault
Trip - OPO fault
Reserved
Reserved
Trip - Unbalance
Trip - Overload
Trip - Overload + phase failure
Trip - Int. earth fault
Trip - Ext. earth fault
Reserved
Trip - Thermistor overload
Trip - Thermistor short circuit
Trip - Thermistor open circuit
Reserved
Trip - TM tripping T>
Trip - TM sensor fault
Trip - TM out of range
Reserved
Trip - Trip I>
Trip - Trip I<
Trip - Trip P>
Trip - Trip P<
Trip - Trip cos phi<
Trip - Trip U<
Trip - Trip 0/4-20 mA>
Trip - Trip 0/4-20 mA<
Trip - Stalled rotor
Reserved
Information
BU1 BU2
BU1 BU2
BU1 BU2
BU1 BU2
BU1 BU2
BU1 BU2
BU1 BU2
BU1 BU2
BU1 BU2
BU1 BU2
BU2
BU2
IM UM
IM UM
IM UM
IM UM
EM
Th
Th
Th
TM
TM
TM
IM UM
IM UM
UM
UM
UM
UM
AM
AM
IM UM
