Siemens SIMOCODE pro System Manual page 74

System description
[mA] In 1/Output (example)
[mA] In 2/Output (example)
[mA] Inputs (example)
Max. temp. °C (example)
Temperatures °C (example)
Table 1-10: Read and adapt main display (Cont.)
1-56
Displays the current value at input 1 of the analog module and at the
output of the analog module in mA.
Note
Only possible if the analog module is used.
Displays the current value at input 2 of the analog module and at the
output of the analog module in mA.
Note
Only possible if the analog module is used.
Displays the current value at both inputs of the analog module
in mA.
Note
Only possible if the analog module is used.
Displays the maximum temperature of all used sensor measuring
circuits of the temperature module in °C.
Note
Only possible if a temperature module is used.
Displays the individual temperatures of all used sensor measuring
circuits of the temperature module in °C.
Note
Only possible if a temperature module is used.
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
