Data formats and data records
B.18

Data record 202 - Acyclic receive

Description
The acyclic receive data can be used for any functions. The receive data is
available as device-internal outputs (sockets).
Byte.Bit
0.0 Reserved
4.0 Acyclic receive - Bit 0.0
4.1 Acyclic receive - Bit 0.1
4.2 Acyclic receive - Bit 0.2
4.3 Acyclic receive - Bit 0.3
4.4 Acyclic receive - Bit 0.4
4.5 Acyclic receive - Bit 0.5
4.6 Acyclic receive - Bit 0.6
4.7 Acyclic receive - Bit 0.7
5.0 Acyclic receive - Bit 1.0
5.1 Acyclic receive - Bit 1.1
5.2 Acyclic receive - Bit 1.2
5.3 Acyclic receive - Bit 1.3
5.4 Acyclic receive - Bit 1.4
5.5 Acyclic receive - Bit 1.5
5.6 Acyclic receive - Bit 1.6
5.7 Acyclic receive - Bit 1.7
6.0 Acyclic receive - Analog value
Table B-19: Data record 202 - Acyclic receive
B-42
Designation Type Information
Byte[4]
Bit
Bit
Bit
Bit
Bit
Bit
Bit
Bit
BU1 BU2
Bit
Bit
Bit
Bit
Bit
Bit
Bit
Bit
Word
