Outputs
Application examples
• Display of operating states:
You can define which LEDs are to be used for displaying the operating states
(Fault, ON, OFF, Fast, Slow...).
For this, connect the desired LED to the respective "QL." lamp control of the
control function.
In many cases, the LEDs are connected to the QL outputs. By referring to
Table 4-21 on page 4-65
for which control functions.
• Transfer of any other information, status information, warnings, faults, etc. to
the yellow LEDs.
Settings
OP LED
Green 1 to Green 4
Yellow 1 to Yellow 3* Control of the "OP LED" function block
Table 6-3: Operator panel LED settings
*) No function when using the operator panel with display
Defaults depend on the selected application (template): See
"Example
6-8
you can determine which QL outputs are required
Control of the "OP LED" function block
with any signal
(any sockets
e.g. feedback concerning the "Motor" operating state)
with any signal
(any sockets
e.g. displays for status, events, faults)
circuits".
