Data formats and data records
B.21.12

Positioner

Bit 0.0
Bit 0.1
Bit 0.2
Bit 0.3
Bit 0.4
Bit 0.5
Bit 0.6
Bit 0.7
Bit 1.0
Bit 1.1
Bit 1.2
Bit 1.3
Bit 1.4
Bit 1.5
Bit 1.6
Bit 1.7
Byte 2/3 *) (analog value)
Bit 0.0
Bit 0.1
Bit 0.2
Bit 0.3
Bit 0.4
Bit 0.5
Bit 0.6
Bit 0.7
Bit 1.0
Bit 1.1
Bit 1.2
Bit 1.3
Bit 1.4
Bit 1.5
Bit 1.6
Bit 1.7
Byte 2/3 (analog value)
Byte 4/5 *) (analog value)
Byte 6/7 *) (analog value)
Byte 8/9 *) (analog value)
Table B-33: Assignment of cyclic receive/send data, positioner
*) for SIMOCODE pro V, basic type 1 only
B-56
Cyclic receive data
Device parameters -> Motor control -> Control stations -> PLC/PCS [DP] -> CLOSED
Device parameters -> Motor control -> Control stations -> PLC/PCS [DP] -> STOP
Device parameters -> Motor control -> Control stations -> PLC/PCS [DP] -> OPEN
Further function blocks -> Standard functions - Test/Reset -> Test 1 - Input
Further function blocks -> Standard functions -> Emergency start -> Emergency start - Input
Device parameters -> Motor control -> Control stations -> Mode selector S1
Further function blocks -> Standard functions -> Test/Reset -> Reset 1 - Input
Not connected
Not connected
Not connected
Not connected
Not connected
Not connected
Not connected
Not connected
Not connected
Not connected
Cyclic send data
Status - ON < (Closed)
Status - OFF (Stop)
Status - ON > (Open)
Event - Pre-warning overload (I>115 %)
Status - Interlocking time active
Status - Remote mode
Status - General fault
Status - General warning
Status - Positioner runs in open direction
Not connected
Status - Positioner runs in close direction
Not connected
Not connected
Not connected
Not connected
Not connected
Maximum current I_max
Not connected
Not connected
Not connected
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
