Siemens SIMOCODE pro System Manual page 482

Tables
No. Designation
121 Status information - Protection
122
123
124 Status information - Miscellaneous
125
126
127
128 Events - Protection
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144 Events - Level monitoring
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
Table A-3: Socket assignment table - digital (Cont.)
A-8
Designation
Status - Emergency start executed
Status - Cooling down period active
Status - Pause time active
Status - Device test active
Status - Phase sequence 1-2-3
Status - Phase sequence 3-2-1
Status - DM-F enabling circuit
Event - Overload operation
Event - Unbalance
Event - Overload
Event - Overload + phase failure
Event - Internal earth fault
Event - External earth fault
Event - Warning ext. earth fault
Event - Thermistor overload
Event - Thermistor short circuit
Event - Thermistor open circuit
Event - TM warning T>
Event - TM Trip T>
Event - TM sensor fault
Event - TM out of range
Reserved
Reserved
Event - Warning I>
Event - Warning I<
Event - Warning P>
Event - Warning P<
Event - Warning cos phi<
Event - Warning U<
Event - Warning 0/4-20 mA>
Event - Warning 0/4-20 mA<
Event - Trip I>
Event - Trip I<
Event - Trip P>
Event - Trip P<
Event - Trip cos phi<
Event - Trip U<
Event - Trip 0/4-20 mA>
Event - Trip 0/4-20 mA<
Event - Stalled rotor
Reserved
Reserved
Event - No start possible
Event - No. of starts >
Information
IM UM
IM UM
IM UM
BU1 BU2
UM
UM
DM-F
IM UM
IM UM
IM UM
IM UM
IM UM
EM
EM
Th
Th
Th
TM
TM
TM
TM
IM UM
IM UM
UM
UM
UM
UM
AM
AM
IM UM
IM UM
UM
UM
UM
UM
AM
AM
IM UM
BU1 BU2
BU1 BU2
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
