Siemens SIMOCODE pro System Manual page 483

No. Designation
165
166
167
168
169
170
171
172 Events - Miscellaneous
173
174
175
176
177
178
179
180
181
182
183
184 Events - Time stamp function
185
186 Events - Miscellaneous
187
188 Events - System interface
189
190 Warnings - Miscellaneous
191
192 Trip - General
193
194
195
196
197
198
199
200 Trip - Controlling
201
202
203
204
205
206
207
Table A-3: Socket assignment table - digital (Cont.)
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
Designation
Event - Just one start possible
Event - Motor operating hours >
Event - Motor stop time >
Event - Limit 1
Event - Limit 2
Event - Limit 3
Event - Limit 4
Event - External fault 1
Event - External fault 2
Event - External fault 3
Event - External fault 4
Event - External fault 5
Event - External fault 6
Reserved
Reserved
Event - Analog module open circuit
Event - DM-F safety-oriented tripping
Event - DM-F - Test requirement
Reserved
Event - Timestamping function active + OK
Reserved
Event - DM-FL safety o.k
Event - PROFIsafe active
Event - Configured operator panel missing
Reserved
Warning - DM-F feedback circuit
Warning - DM-FL simultaneity
Trip - HW fault basic unit
Trip - Module fault (e.g. IM, DM)
Trip - Temporary components (e.g. memory
module)
Trip - Configuration fault
Trip - Parameterization
Trip - Bus
Trip - PLC/PCS
Reserved
Trip - Execution Time ON
Trip - Execution time OFF
Trip - FB ON
Trip - FB OFF
Trip - Stalled positioner
Trip - Double 0
Trip - Double 1
Trip - End position
Tables
Information
BU1 BU2
BU1 BU2
BU1 BU2
BU2
BU2
BU2
BU2
BU1 BU2
BU1 BU2
BU1 BU2
BU1 BU2
BU2
BU2
AM
DM-F
DM-F
BU2
DM-FL
DM-FP
BU1 BU2
DM-F
DM-FL
BU1 BU2
BU1 BU2
BU1 BU2
BU1 BU2
BU1 BU2
BU1 BU2
BU1 BU2
Not for overload relays
Positioner
Solenoid valve/positioner
Solenoid valve/positioner
Solenoid valve/positioner
