Application examples
Typical applications are:
• Fill-level monitoring for implementing dry running protection for pumps
• Monitoring of pollution in a filter using a differential pressure transducer.
Settings
Analog module
Input signal
Response at open circuit
Active inputs
Table 7-8: Analog module input settings
Note
Note
The value of the analog module inputs is in S7 format.
Notice
The inputs of the analog module are passive inputs, i.e. to configure an
analog input circuit, each input will require an additional, isolated external
current source connected in series. If the output of the analog module is not
being used by another application, it can also be used as a current source
for an analog module input circuit. The "Start value of value range" and the
"End value of value range" of the analog module output have to be set to
65535 for this. Thus, the maximum possible current will always be available
via the analog module output.
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
Description
0-20 mA, 4-20 mA
Signaling, warning, tripping
1 input, 2 inputs
Inputs
