Types of signals/output responses
Level not inverted
Level inverted
Edge rising with memory
Edge falling with memory
Fig. 11-15: Signal types/output responses of non-volatile elements
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
Input
Reset
Output
Input
Reset
Output
Input
Reset
Output
Input
Reset
Output
Logic modules
Voltage failure
Voltage failure
11-19
