Siemens SIMOCODE pro System Manual page 347

Circuit and parameterization
Circuit:
S1
S2
S3
Parameterization with SIMOCODE ES
Connect inputs, i.e.
Connecting plugs with sockets
Fig. 11-4: Example circuit and parameterization for truth table 3I/1O
Settings
Truth tables 1-6 3I/
1O -
Input 1 to 3
Table 11-2: Settings for truth table 3I/1O
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
BU Inputs
1 Input 1
Input 2
2
3 Input 3
4
Activate the truth table with any signal
(any sockets
e.g. device inputs, control bits from PROFIBUS DP , etc.)
BU
Truth Table 1 3I/1O
Output
Description
Logic modules
L1
N
Q1
BU Outputs
1
2
Out1
3
Set bits for
output signals
11-5
