12.5.4 Integration of SIMOCODE pro as SIMATIC PDM object (DPV1 slave via
GSD) in STEP7 HW Config
SIMOCODE pro can be integrated as a PDM object in the STEP7 HW Config
of the SIMATIC PDM (Process Device Manager) software from version 6.0 +
SP1 onwards. The PDM option "Integration in STEP7" is required for this.
The following table describes how you can insert SIMOCODE pro as a PDM
object in the STEP7 HW Config from the hardware catalog.
Step
1
2
3
4
5
Table 12-10:
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
STEP7 , V5.1+SP2 onwards
Start STEP7 and open the "HW Config".
To integrate SIMOCODE pro as a PDM object, navigate to the
"PROFIBUS DP > Devices" directory in the hardware catalog.
Enter
"SIMOCODE pro C (PDM)" or
"SIMOCODE pro V (PDM)" on the PROFIBUS.
Only for SIMOCODE pro V:
SIMOCODE pro V can be connected in two basic types (basic type 1 or
basic type 2). See Chapter
If you wish to use "basic type 1", delete the default "basic type 2" module
and insert "basic type 1" instead.
Only for the failsafe digital module DM-F PROFIsafe: Insert the
"PROFIsafe" module into the second position (in addition to "basic type 1"
or "basic type 2".)
You can find further information on using DM-F PROFIsafe in the system
manual "Failsafe Digital Modules SIMOCODE pro SAFETY ".
Check the set DP alarm mode (DPV0 or DPV1) as well as the release of
the DPV-1 alarms in the properties of the DP slave.
These settings influence the evaluation of the diagnostics data and alarms
(see Chapter 12.6 "Evaluating diagnostics data"
"Timestamping").
Start SIMATIC PDM to create the device parameters by double clicking on
the slave symbol (see Chapter
Integration of SIMOCODE pro as SIMATIC PDM object (DPV1 slave via GSD) in
STEP7 HW Config
12.4.1 "Cyclic data". The default is basic type 2.
and Chapter 10.10
12.8.2 "SIMATIC PDM").
