12.8.3

Parameter data during startup

Parameters are transferred to the device during every startup of
SIMOCODE pro on PROFIBUS DP .
Depending on the master module and the type of integration used, either
standard parameters or standard parameters and device-specific
parameters (SIMOCODE pro parameters) are transferred. The parameters
are saved in the PLC or in the DP master and are transferred automatically
to the DP slave during the system startup.
You can set the device-specific parameters:
• With the configuration tool when the GSD (BU1 only) is loaded, e.g. with
STEP7 HW Config. This option is available for SIMOCODE pro C. The
SIMOCODE pro parameters are created by configuring the device-specific
parameters in the slave properties.
• In the "SIMOCODE ES" software during the integration of SIMOCODE pro in
STEP7 HW Config as an S7 slave via OM SIMOCODE pro.
This option is available for SIMOCODE pro C and SIMOCODE pro V. You can
start the "SIMOCODE ES" software for easy configuration of the
parameterization from STEP7 HW Config using the button in the "Parameter"
tab in the object properties of slot 4.
Notice
In order to be able to carry out the device parameterization during startup,
the startup parameter block ("Device Parameter > Bus Parameter") must
remain unset.
SIMOCODE pro is then parameterized with the device-specific parameters
stored in the DP master, and any existing parameters in the device are
overwritten.
