Notice
Only a current/voltage measuring module may be connected to the system
interface on the right of the decoupling module. Memory modules,
addressing plugs or PC cables will not be recognized there.
Notice
Observe the color coding for the connecting cable (see diagram)!
13.4.3
System interfaces on the digital modules DM-F Local or DM-F PROFIsafe
See system manual "Failsafe Digital Modules SIMOCODE pro SAFETY",
Chapter 5 "Mounting and connection".
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
Mounting, wiring, interfaces
13-41
