Data Record 133 - Extended Device Parameters; (Plug - Siemens SIMOCODE pro System Manual

B.14

Data record 133 - Extended device parameters 2

(plug

Byte. Designation
Bit (PRM group)
0.0 Reserved
4.0 Byte parameters (41)
4.0 DM1 - Output 1
5.0 DM1 - Output 2
6.0 DM2 - Output 1
7.0 DM2 - Output 2
8.0 Reserved
9.0 Reserved
10.0 Reserved
11.0 Reserved
12.0 Timestamping - Input 0
13.0 Timestamping - Input 1
14.0 Timestamping - Input 2
15.0 Timestamping - Input 3
16.0 Timestamping - Input 4
17.0 Timestamping - Input 5
18.0 Timestamping - Input 6
19.0 Timestamping - Input 7
20.0 Analog value recording - Trigger input
21.0 Reserved
22.0 Control station - Local control [LC] ON <<
23.0 Control station - Local control [LC] ON >>
24.0 Control station - PLC/PCS [DP] ON <<
25.0 Control station - PLC/PCS [DP] ON >>
26.0 Control station - PC[DPV1] ON <<
27.0 Control station - PC[DPV1] ON >>
28.0 Control station - Operator panel [OP] ON >> Byte
29.0 Control station - Operator panel [OP]<>/
<<>>
30.0 Control function - ON <<
31.0 Control function - ON >>
32.0 Auxiliary control input - FC
33.0 Auxiliary control input - FO
34.0 Auxiliary control input - TC
35.0 Auxiliary control input - TO
36.0 External fault 5 - Input
37.0 External fault 6 - Input
Table B-15: Data record 133 - Extended device parameters
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
)
Type
Byte[4]
Byte
Byte
Byte
Byte
Byte
Byte
Byte
Byte
Byte
Byte
Byte
Byte
Byte
Byte
Byte
Byte
Byte
Byte
Byte
Byte
Byte
Byte
Byte
Byte
Byte
Byte
Byte
Byte
Byte
Byte
Byte
Byte
Byte
Data formats and data records
Range De-
fault
0 .. 255 0
0 .. 255 0
0 .. 255 0
0 .. 255 0
0
0
0
0
0 .. 255 0
0 .. 255 0
0 .. 255 0
0 .. 255 0
0 .. 255 0
0 .. 255 0
0 .. 255 0
0 .. 255 0
0 .. 255 0
0
0 .. 255 0
0 .. 255 0
0 .. 255 0
0 .. 255 0
0 .. 255 0
0 .. 255 0
0 .. 255 0
0 .. 255 0
0 .. 255 0
0 .. 255 0
0 .. 255 0
0 .. 255 0
0 .. 255 0
0 .. 255 0
0 .. 255 0
0 .. 255 0
Note Informa-
tion
DM1
DM-F
DM1
FM-F
DM2
DM2
BU2
BU2
BU2
BU2
BU2
BU2
BU2
BU2
BU2
Dependen
t on the
control
function
BU2
BU2
B-37
