Communication
Channel-related diagnostics - definition
Channel-related diagnosis is a detailed version of the identification-related
diagnostics. It supplies information about the device faults of
SIMOCODE pro.
Channel-related diagnostics - configuration
The channel-related diagnostics is configured as follows:
Byte 28
Byte 29
Byte 30
Byte 31 to
byte 33
Fig. 12-7: Configuration of the channel-related diagnostics
The block for the channel-related diagnostics, which has a length of 3 bytes,
is either missing (if there is no channel-related diagnostics) or is available
once or twice.
Error types
The diagnostic message is output on channel 0.
No.
F9 01001:
Error
F16 10000:
Parameterization
error
Table 12-7: Error types
12-14
7 6 5
1 0 0 0 0 0 x x
Code for channel-related diagnostics
7 6 5
1 1 0 0 0 0 0 0
Input/output channel
7 6 5
0 0 0
Error type 9 or 16 (table below)
Channel type:
000 : No special channel type
B
Next channel-related diagnostic message
(Allocation as for byte 28 to 30)
Error type Meaning/cause
• Internal fault/device fault
• Error during self-test
• Incorrect parameter value
0 Bit number
0x80 GSD
0x83 OM SIMOCODE pro
0 Bit number
0 Bit number
Exact information: See
Chapter
92 - Device
GWA 4NEB 631 6050-22 DS 03
B.8 "Data record
diagnostics".
