Byte Setup 3UF50 - device-specific
Bit
diagnostics acc. to DP
standard SIMOCODE-DP
9.7 Warning: Thermistor
10.0 Trip: Earth fault
10.1 Trip: Overload
10.2 Trip: Overload + unbalance
10.3 Trip: I1 response level overshot
10.4 Trip: I1 response level undershot 13.4
10.5 Trip: I2 response level overshot
10.6 Trip: I2 response level undershot 13.6
10.7 Trip: Thermistor
11.0 Trip: FB ON
11.1 Trip: FB OFF
11.2 Trip: Motor blocked
11.3 Trip: Positioner blocked
11.4 Trip: Double 0
11.5 Trip: Double 1
11.6 Trip: End position
11.7 Trip: Antivalence
12.0 Trip: ESB
12.1 Trip: OPO
12.2 Trip: UVO
12.3 Trip: Ext. fault 1
12.4 Trip: Ext. fault 2
12.5 Trip: TPF fault
12.6 Trip: Runtime ON
12.7 Trip: Runtime OFF
13.0 Trip: Parameter fault 0
13.1 Trip: Parameter fault 1
13.2 Trip: Parameter fault 2
13.3 Trip: Parameter fault 3
13.4 Trip: Parameter fault 4
13.5 Trip: Parameter fault 5
13.6 Trip: Parameter fault 6
13.7 Trip: Parameter fault 7
Table 9-3: Diagram of the diagnostics data in the 3UF50 compatibility mode (Cont.)
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
Byte Setup 3UF50 - device-specific
Bit
diagnostics acc. to
SIMOCODE-DP DPV1 standard
12.7 Warning: Thermistor
13.0 Trip: Earth fault
13.1 Trip: Overload
13.2 Trip: Overload + unbalance
13.3 Trip: I1 response level overshot
Trip: I1 response level undershot Trip - Trip level I<
13.5 Trip: I2 response level overshot
Trip: I2 response level undershot -
13.7 Trip: Thermistor
14.0 Trip: FB ON
14.1 Trip: FB OFF
14.2 Trip: Motor blocked
14.3 Trip: Positioner blocked
14.4 Trip: Double 0
14.5 Trip: Double 1
14.6 Trip: End position
14.7 Trip: Antivalence
15.0 Trip: ESB
15.1 Trip: OPO
15.2 Trip: OPO
15.3 Trip: Ext. fault 1
15.4 Trip: Ext. fault 2
15.5 Trip: TPF fault
15.6 Trip: Runtime ON
15.7 Trip: Runtime OFF
16.0 Trip: Parameter fault 0
16.1 Trip: Parameter fault 1
16.2 Trip: Parameter fault 2
16.3 Trip: Parameter fault 3
16.4 Trip: Parameter fault 4
16.5 Trip: Parameter fault 5
16.6 Trip: Parameter fault 6
16.7 Trip: Parameter fault 7
3UF50 compatibility mode
Equivalent in SIMOCODE pro V
• Warning - Thermistor overload
• Warning - Thermistor open circuit
• Warning - TM warning T>
• Warning - TM sensor fault
• Warning - TM out of range
• Trip - Int. earth fault
or
• Trip - Ext. earth fault
Trip - Overload
Trip - Overload + phase failure
Trip - Trip level I>
-
• Trip - Thermistor overload
• Trip - Thermistor short circuit
• Trip - Thermistor open circuit
• Trip - TM trip T>
• Trip - TM sensor fault
• Trip - TM out of range
Trip - Feedback ON
Trip - Feedback OFF
Trip - Stalled rotor
Trip - Stalled positioner
Trip - Double 0
Trip - Double 1
Trip - End position
Trip - Antivalence
Trip - Ext. fault 4
Trip - Operational protection OFF (OPO)
Trip - Undervoltage (UVO)
Trip - Ext. fault 1
Trip - Ext. fault 2
Trip - Cold starting (TPF) fault
Trip - Execution ON command
Trip - Execution STOP command
Trip - Parameterization
-
-
-
Trip - Configuration fault
-
-
Trip - HW fault basic unit
