Siemens SIMOCODE pro System Manual page 96

System description
Digital module 1 as DM-F Local
Inputs DM-F Local
Sensor channels DM-F Local
Outputs DM-F Local
Digital module 1 is DM-F PROFIsafe
Inputs DM-F PROFIsafe
Outputs DM-F PROFIsafe
Table 1-15: Displays the current status of all device I/Os (Cont.)
1-78
Inputs "IN", "Start", "Feedback circuit", "Cascaded".
Note
Only possible if digital module 1 is "Local", an OPD above version
*E04* and BU2 above *E07* is being used.
Sensor channels 1,2
Note
Only possible if digital module 1 is "Local", an OPD above version
*E04* and BU2 above *E07* is being used.
Outputs 1, 2, "Enabling circuit".
Note
Only possible if digital module 1 is "Local", an OPD above version
*E04* and BU2 above *E07* is being used.
Inputs 1, 2, 3, "Feedback circuit".
Note
Only available if digital module 1 is "PROFIsafe" and if an OPD above
version *E04* and BU2 above *E07* is being used.
Outputs 1, 2, "Enabling circuit".
Note
Only available if digital module 1 is "PROFIsafe" and if an OPD above
version *E04* and BU2 above *E07* is being used.
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
