Logic modules
11.10

Flickering

Description
You can use the "Flickering" logic modules to assign the "Flickering" function
to the operator panel LEDs (for example).
If an input signal is pending, the "Flickering" function block issues an output
signal with a frequency of 4 Hz.
The function block consists of:
• One plug
• One logic component
• One socket.
Overall, three logic modules, "Flickering 1" through to "Flickering 3" are available
for BU1 and BU2.
Schematic
The following schematic shows the "Flickering" logic modules:
Input
Input
Fig. 11-17: "Flickering" logic modules
Settings
Flickering 1 to 3 -
Input
Table 11-11: Flickering settings
11-22
Flickering 1
Output
Flickering 3
Output
Activation by any signal
(any sockets ,
e. g. status information etc.)
Flickering 2
Input
Description
GWA 4NEB 631 6050-22 DS 03
Output
SIMOCODE pro
