Siemens SIMOCODE pro System Manual page 467

Event Description
(alphabetical)
DM-FL - The DM-F Local is in
Configuration "Configuration mode";
mode The "DEVICE" LED on the front
of the DM-F Local is lit yellow.
DM-FL - Cross DM-F Local sensor circuit cross
circuit circuit.
The "GF" (Gen. Fault) LED on the
front of the DM-F Local is lit red.
DM-FL - The DM-F Local has detected a
Simultaneity discrepancy fault in the two-
channel sensor circuit.
DM-FL waiting The DM-F Local is in the
for start-up test "Waiting for start-up test" state.
DM-FP F PRM The specified PROFIsafe profile
error parameters are erroneous or the
specified
PROFIsafe address does not
correspond to the configuration.
Double 0 Both torque switches have
activated simultaneously. The
motor feeder has been turned
off.
Double 1 Both limit switches have
activated simultaneously.
End position Except positioner 5 control
function: The state of the limit
switch has changed without a
command (positioner has left
the end position without a
command)
Execution The motor feeder could not be
ON command turned on after an ON command
is issued.
Table 15-1: Alarms, faults and system events (Cont.)
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
Alarms, faults and system events
Troubleshooting Acknowledg
ement/fault
rectification
Complete the
configuration (see
system manual "Failsafe
Digital Module
SIMOCODE
pro Safety", Chapter 7.4)
• Check the wiring of Reset
both sensor circuits for
cross circuiting
• Rectify the fault.
Please check the contact Rectify the
blocks in the sensor fault by
circuit. opening or
closing the
sensor
inputs
Carry out the start-up
test by actuating the
sensor in the sensor
circuit.
Please check the
PROFIBUS/PROFIsafe
parameters of
SIMOCODE pro, which
were set on the DP
Master system.
• Open circuit torque
switch.
• Torque switch is
defective.
Limit switch is defective.
"OPEN/
CLOSED"
counter
command.
• Main circuit is Reset or
interrupted (fuse, OFF
circuit breaker) command/
• The motor contactor or counter-
contactor control is command
defective
• Parameter execution
time is too short.
Contactor Error
control no.*)
Tripped
Tripped
Tripped 13
Tripped 14
Tripped 15
Tripped
15-3
