System description
Device I/Os
Display settings
Commands
Status information
Warnings
Table 1-9: Menu of the operator panel with display and menu navigation (Cont.)
1-52
The "Device I/Os" menu item provides a complete overview of the
current status of all inputs and outputs of the basic unit as well as
any connected expansion modules.
For detailed information, see:
device I/Os".
All settings relevant to the operator panel with display can be
carried out via "Display Settings". In addition to selecting the
language and adjusting the contrast or illumination, it is also
possible to select the profiles here which are relevant for adjusting
the main display.
For detailed information, see:
The "Commands" menu item contains all commands relating to
SIMOCODE pro e.g. for testing the feeder, resetting after tripping
and/or adopting parameters into the memory module or into
SIMOCODE pro.
For detailed information, see
via commands".
The "Status Information" menu item provides an overview of all
pending status information.
For detailed information, see
information".
The "Warnings" menu item provides an overview of all pending
warnings.
For detailed information: See
"Displays the current status of all
"Adapt display settings".
"Resetting, testing and parameterizing
"Display of all pending status
"Display of all pending warnings".
