Logic modules
Settings
Timers 1 to 4 -
Input
Reset
Type
Value
Table 11-5: Timer settings
11-14
Activation by any signal
(arbitrary sockets , e.g. device inputs, control bits from
PROFIBUS DP , etc.)
Resets the actual value to 0.
Activation by any signal
(arbitrary sockets , e.g. device inputs, control bits from
PROFIBUS DP , etc.)
Different output responses
Range: Closing delay, closing delay with memory,
opening delay, fleeting closing
Time during which the timer provides an output signal when
activated, depending on the output response (type)
Range: 0 to 65535, unit 100 ms
Description
