Max. temp. °F (example)
Temperatures °F (example)
UL1-N, UL2-N, UL3-N
UL1-L2, UL2-L3, UL3-L1
I_max, UL1-N, Cos
Table 1-10: Read and adapt main display (Cont.)
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
Displays the maximum temperature of all used sensor measuring
circuits of the temperature module in °F.
Note
Only possible if a temperature module is used.
Displays the individual temperatures of all used sensor measuring
circuits of the temperature module in °F.
Note
Only possible if a temperature module is used.
Displays phase voltages UL1-N, UL2-N and UL3-N in V.
Note
Only possible if a current/voltage measuring module is being used.
If an OPD above version *E04* is used: Values will only be
displayed if phase voltage is set/configured.
Shows line-to-line voltages UL1-L2, UL2-L3, UL3-L1 in V.
Note
Only possible if a current/voltage measuring module is being used,
line-to-line voltage is set/configured and the OPD is above version
*E04*.
Displays the maximum current of all three phases in A, the phase
voltage UL1-N in V and the power factor.
Note
Only possible if a current/voltage measuring module is being used.
If an OPD above version *E04* is used: Values will only be
displayed if phase voltage is set/
configured.
