Transferring parameters to the basic unit and commissioning
After creating the parameter file, you can transfer it to SIMOCODE pro and
commission the reversing starter.
Proceed as follows:
Step
1
2
3
4
5
Table 2-4: Transferring the parameters to the basic unit and commissioning
Notice
Switching between "RIGHT" and "LEFT" is only possible via "OFF" after the
preset, 5-second interlocking time has expired.
Configuration with local control station completed
The configuration with SIMOCODE pro is now complete. You now have a
functional reversing starter with a local control station.
If the wiring and parameterization are correct, the contactors for clockwise
and counterclockwise rotation will be activated when the corresponding
buttons are pushed.
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
Short instructions for configuring a reversing starter
Switch on the voltage supply of the basic unit.
Connect the serial interface of the PC/programming device and the system
interface of the basic unit using the PC cable.
Observe the status LED on the basic unit. The "Device" LED should light up
green. SIMOCODE pro can be started up.
Transfer the parameter file to the basic unit via the menu, e.g. using Target
System > Download to Device. Select the RS232 interface with which
SIMOCODE pro is connected to the PC via the PC cable.
After transferring the data to the basic unit, you will receive the message
"Download to device successfully accomplished".
Description
2-9
