Technical data
D.2

Technical data of the basic units

Mounting
Display
• Red/green/yellow "DEVICE" LED
• Green "BUS" LED
• Red "GEN. FAULT" LED
"TEST/RESET" button
System interfaces
• Front
• Bottom
PROFIBUS DP interface
• Interface design
• Connection system
Rated control supply voltage U
(according to DIN EN 61131-2)
Operating range
Power consumption
• Basic unit 1 (3UF7000)
• Basic unit 2 (3UF7010)
(including two expansion modules
connected to basic unit 2)
Rated insulation
voltage U
i
Rated impulse withstand voltage
U
imp
D-4
Snap-on mounting onto 35 mm standard mounting rails or
screw attachment via additional plug-in lugs
• Red: "Function test was negative, device is blocked"
• Green: "Ready for operation"
• Yellow: "Memory module or addressing plug detected"
• OFF: "No control supply voltage"
• Continuous light: "Communication with PLC/PCS"
• Flashing: "Baud rate recognized/communication with PC/
programming device"
Continuous light/flashing: "Feeder fault", e.g. overload tripping
• Resetting the device after tripping
• Function test (system self-test)
• Operation of memory module, addressing plug
For connecting an operator panel or expansion modules. The
memory module, addressing plug or a PC cable can also be
connected to the system interface for parameterization
purposes.
For connecting a current measuring module or current/
voltage measuring module
RS485
9-pole SUB-D socket (12 MBit)
Terminals (1.5 MBit), connection cross section as per control
circuit
Connection of a PROFIBUS DP cable via terminal connection or
9-pole SUB-D socket.
110 V - 240 V AC/DC 50/60 Hz
s
0.85 x Us - 1.1 x Us -
7 VA/5 W
10 VA 7 W
300 V (for Degree of Pollution 3)
4 kV
24 V DC
0.8 x Us - 1.2 x Us -
5 W
7 W
