Data formats and data records
Byte Designation
Bit (PRM group)
23.6 Reserved
24.0 Bit[4] - Parameters (24)
24.0 External fault 1 -
Reset also by
24.4 External fault 2 -
Reset also by
25.0 External fault 3 -
Reset also by
25.4 External fault 4 -
Reset also by
26.0 Limit monitor - Hysteresis for
limit monitors
26.4 Reserved
27.0 Reserved
27.4 Reserved
28.0 Byte parameters (28)
28.0 Internal earth fault - Delay
29.0 Overload protection - Class
30.0 Motor protection - Delay
with overload operation
31.0 Motor protection - Unbalance
level
32.0 Unbalance protection - Delay
with unbalance
33.0 Interlocking time
34.0 FB time
35.0 Trip level I>
36.0 Warning level I>
37.0 Trip level I<
38.0 Warning level I<
39.0 Stalled rotor level
40.0 Trip delay I>
41.0 Warning delay I>
42.0 Trip delay I<
43.0 Warning delay I<
44.0 Blocking delay
45.0 Monitoring the number of
starts - Permissible starts
46.0 Reserved
47.0 Reserved
48.0 Truth table 1 type 3I/1O
49.0 Truth table 2 type 3I/1O
50.0 Truth table 3 type 3I/1O
51.0 Reserved
Table B-12: Data record 130 - Basic device parameters 1 (Cont.)
B-24
Type Range De-
fault
Bit[2] 0
Bit[4] 0 - 1111B 0101B Bit[0] = Panel reset
Bit[4] 0 - 1111B 0101B
Bit[4] 0 - 1111B 0101B
Bit[4] 0 - 1111B 0101B
Bit[4] 0 .. 15 5
Bit[4] 0
Bit[4] 0
Bit[4] 0
Byte 0 .. 255 5
Byte 5, 10 .. 35, 10
40
Byte 0 .. 255 5
Byte 0 .. 100 40
Byte 0 .. 255 5
Byte 0 .. 255 0
Byte 0 .. 255 5
Byte 0 .. 255 0
Byte 0 .. 255 0
Byte 0 .. 255 0
Byte 0 .. 255 0
Byte 0 .. 255 0
Byte 0 .. 255 5
Byte 0 .. 255 5
Byte 0 .. 255 5
Byte 0 .. 255 5
Byte 0 .. 255 5
Byte 1 .. 255 1
Byte 0
Byte 0
Byte 0 .. 11111111B 0
Byte 0 .. 11111111B 0
Byte 0 .. 11111111B 0
Byte 0
Note
Bit[1] = Auto-reset
Bit[2] = Remote reset
Bit[3] = OFF command reset
0 = Deactivated
