Monitoring functions
Trip level, warning level
With active power monitoring, you can parameterize two different response
levels (trip level/warning level) for the upper and lower limit.
Trip level
• P> (upper limit)
• P< (lower limit)
Warning level
• P> (upper limit)
• P< (lower limit)
Trip level and warning level activity
The trip level/warning level is only effective when the motor is running, the
start-up procedure has been completed and there is no test position
feedback (TPF) (run+).
Response when trip level P> (upper limit), P< (lower limit)
Here you can set how SIMOCODE pro should respond if the set trip level is
either undershot or overshot:
See also "Tables of responses of SIMOCODE pro" in
information".
Response
Deactivated
Signaling
Warning
Tripping
Delay
Table 5-11: "Trip level" response for active power monitoring
Response when warning level P> (upper limit), P< (lower limit)
Here you can set how SIMOCODE pro should respond if the set warning
level is either undershot or overshot:
See also "Tables of responses of SIMOCODE pro" in
information".
Response
Deactivated
Signaling
Warning
Tripping
Delay
Table 5-12: "Warning level" response for active power monitoring
5-14
0.000 - 4294967.295 kW
0.000 - 4294967.295 kW
Trip level
X
X
-
X
0 - 25.5 s (0.5 s)
Warning level
X
X
X
-
0 - 25.5 s (0.5 s)
Chapter "Important
Chapter "Important
